Product information:
Power type: Battery
Packing specification: Color box size 97*82*35mm
Weight: 120G
1. Main control: XR872
2. Memory: 32Mb flash
3. Sensor: 30W GC0328 CMOS sensor 4. Lens: 100° wide Angle lens
Sensor performance: Support automatic white balance, automatic gain control, automatic backlight compensation
5. SNR: ≥41dB
6. Minimum illumination: 0.8Lux/F1.4 (color mode),0.3Lux/F1.4 (black and white mode)
7. Night vision: 2 850nmΦ28Mil high-power red lights night vision distance: 1 meter effect is the best, the farthest distance is 3 meters
8. Video format: JPG
9. Video size/frame rate: 480P/7fps
10. Recording method :1. Key trigger recording;
11. Cloud Storage Diagram :5 seconds (5 pictures)
12. Battery type/capacity: polymer 803035/800MAH Battery discharge time: polymer battery hibernation standby for 1 year
13. The network protocol: HTTP/TCP/UDP/TCP/IP/DHCP/DNS/DDNS/NTP/RTP/P2P
WIFI connection :2.4GHz wifi, support (802.11b /g/n)
14. Ding dong: Supports RF 433MHZ ding dong
15. Storage: Support cloud storage function (without TF card function),3 days free cycle cloud storage"
16. Working voltage: polymer 803035/3.7V
17. Working current: working current 219mA, deep sleep current 10mA, infrared operating current 280mA
18.USB charging voltage: DC 5V / 1.5A
19. Storage temperature (℃) : (0℃ ~ 50℃)
20. Operating temperature (℃) : -10 ~ 50℃, working humidity <95%
Wake-up mode: 1. Doorbell button wake-up,
APP doorbell access rules: 1 main account +8 sharing accounts =9 users can be connected to the doorbell, each time only 3 users can preview the screen, each time only one user can talk to the doorbell"
Usage: Guests can visit the video voice call, short time video recording, the host does not need to open the door to know the information of the visitor
Features: Wireless connection, ultra-low power consumption, multiple accounts can be simultaneously online viewing
Power consumption: 0.04 (W)
